Introduction to ARP

Potential Breaking Changes

ARP is still at an early stage, and active development is happening with new features every week. This creates the risk of breaking changes.

Click to expand

The ARP Standard

The ARP Standard is versioned by API namespace (for example /v1/...). When the standard needs to introduce breaking HTTP contract changes, it will do so under a new namespace (for example /v2/...).

The JARVIS Stack

JARVIS is the first-party OSS implementation stack. Implementation details and CLI UX may evolve as the stack matures. For deployment and local bring-up, use the version-pinned JARVIS_Release stack and the arp-jarvis CLI.

This documentation is kept up-to-date to the latest release of both the ARP Standard and the JARVIS OSS Stack.

Agent Runtime Protocol (ARP) is an evolving set of contracts and components for running capability-oriented, bounded, auditable agentic workflows across runtimes, tools, model providers, and environments.

ARP is opinionated about one thing: reliability comes from enforceable bounds + durable artifacts, not from “better prompts”.

Capability Oriented Programming

Capability Oriented Programming (COP) is the core of everything we are building here. It is the mindset: define capabilities you can evaluate, publish, and reuse with evidence.

Agent Runtime Protocol makes COP operational by defining the node-centric execution fabric: NodeTypes, NodeRuns, candidate sets, policy checkpoints, events, and artifacts.

JARVIS is the first-party OSS implementation of the ARP Standard services (plus a few practical internal services for durability/audit).

If you are curious about COP and how this shapes ARP, start here: Fundamentals (COP + ARP Concepts).

Standard vs. Implementation

	ARP Standard	JARVIS Implementations
What it is	Versioned HTTP+JSON contracts (OpenAPI + JSON Schema + conformance)	First-party OSS components that implement the contracts (plus non-spec internals)
Source of truth	ARP_Standard/spec/v1/	JARVIS_Release + component repos
Primary audience	Implementers of ARP-compatible services and SDKs	Users running ARP services and extending the stack
Docs in this site	ARP Standard	JARVIS Implementation
Python packaging	Packages: arp-standard-model, arp-standard-client, arp-standard-server	Pinned stack: arp-jarvis

Across this documentation portal, you may see some features are marked as WIP while the ecosystem is actively being built.

Quickstart

See ARP run with the end-to-end Quickstart on the JARVIS first party OSS reference implementation:

• JARVIS Quickstart

Version pinning

For local bring-up and repeatable builds, prefer the version-pinned stack distribution repo:

• JARVIS_Release (Docker Compose baseline + stack.lock.json)

Use arp-jarvis stack as the default way to bring the stack up and down. Running services outside Docker is supported but is considered an advanced path.

---

Core services

ARP Standard v1 defines the node-centric execution fabric service set:

• Run Gateway — client entrypoint: start/get/cancel runs (+ optional event streaming)
• Run Coordinator — run authority: lifecycle, enforcement, scheduling/dispatch, audit history
• Atomic Executor — executes atomic NodeRuns (strict request/response envelopes)
• Composite Executor — executes composite NodeRuns (planner/arg-gen/eval hooks; internals not standardized)
• Node Registry — catalogs NodeTypes (metadata; versions; deprecation)
• Selection — generates bounded candidate sets for mapping subtasks to NodeTypes
• PDP (optional) — returns policy decisions (allow/deny/require-approval)

JARVIS also ships non-spec internal services (Run Store, Event Stream, Artifact Store) as practical building blocks for durability and audit.

System Diagram

High-level topology (typical JARVIS deployment):

Client
  │
  ▼
Run Gateway ─────► Run Coordinator ─────► Atomic Executor(s)
                      │   │
                      │   ├─────────────► Composite Executor(s)
                      │   │                  │
                      │   │                  └─────────────► Selection Service
                      │   │                                     │
                      │   │                                     └─────────────► Node Registry
                      │   │
                      │   └─────────────► PDP (optional)
                      │
                      ├─────────────► Run Store (non-spec)
                      ├─────────────► Event Stream (non-spec)
                      └─────────────► Artifact Store (non-spec)

---

What you'll find here

• Quickstart (Full stack): Run a minimal end-to-end JARVIS stack locally.
• Fundamentals: COP mindset + ARP concepts.
• How-to Guides: Copy/paste recipes for doing one thing at a time.
• ARP Standard (Spec): Required endpoints, schemas, conformance, SDKs.
• JARVIS implementation: Reference behavior, defaults, and deployment notes.
• Integrations: How ARP/JARVIS fits with MCP, A2A, and other ecosystems.
• Helper Libraries: Shared packages used across components (arp-auth, arp-llm, arp-policy).
• Extra Resources: Roadmap, glossary, changelog, FAQ.

---

Next steps

If you're new and eager to try ARP out, begin with the Quickstart Guide.
